DT60 Kit 1: Support Face, password verification. NOT Support RFID Card. Not support WiFi. DT60-RFID Kit 2: Support Face, password verification. Support RFID Card. Not Support WiFi. DT60-WIFI Kit 3: Support Face, password verification.Support WiFi. Not Support RFID Card. DT60-TOP Kit 4: Support Face, password verification. Support RFID Card. Support WiFi.

Dynamic Face Facial Recognition Access Control Time Attendance Machine

This a newest dynamic facial recognition access control time attendance machine. Support WIFI(optional) / TCP/ IP communication method. Support face, password, RFID cards(optional) to identify.

Product Features:

1) 4.3inch TFT LCD Color screen. Made of high quality material. 2) Working with DC12V, will supply a DC12V power plug. 3) Has high-resolution infrared night vision light and professional color duo camera, can carry out quick verification in any environment. 4) Dual light source ( 2 infrared light + white light). Can be recognize even at dark. 5) 0.1s identification speed, Very fast! Support face detection distance 0.5-4 Meters. 6) Working with both 125KHz and 13.56MHz frequency. Support both EM and Mi-fare cards. 7) Support facial, password, RFID card (Optional ), 200000 record capacity. User capacity: 2000pcs and 5000pcs optional (Default is 2000pcs). 8) Supports face, password, RFID card and various combination methods, in order to satisfy the demands of different users.(optional) 9) T9 input method editors, on the machine name, Department, frequency and other information, can be directly output attendance reports, very easy to operate. 10) Support WIFI / TCP/ IP communication method. Support USB Flash drive upload download attendance data. (Optional) 11) Has Wiegand26/34 input/output, TTL input/output, relay output 12) Support English menu and humanized voice prompt. 13) Recognizes normally even when wearing a mask. Can't be recognize with photos or video. 14) Suitable for the entrances and exits of office, factory, hotel, school, etc.

Product Details:

1, 4.3inch TFT LCD Touch Color Screen. English interface. Very easy to operate.

2, Dynamic Face Identification. Save a lot of time Wide angle detection of dynamic faces, fast face recognition in 0.1 seconds the recognition distance is up to 2 meters.

3, Intelligent face recognition, Easily deal with all kinds of problems Item not only prevents employees from using photo or video attendance, but also intelligently recognizes changes in your appearance. Even if you have makeup, hats, and glasses, you can quickly identify them without queuing.

4, Built in HD Dual light source ( 2 infrared light + white light), can be recognize even at dark With its high-resolution infrared night vision light and professional color duo camera, it can accurately identify and verify the second speed even in the extremely dark or extremely bright environment.

5, Support both 2 types RFID Card verification (Optional) Support smart sensing technology, identify sensitive, you can open the door with RFID card convenient. Works with both 125KHz and 13.56MHz frequency, EM and Mi-fare cards. (not all machine support this function).

6, Large capacity. Don't worry about the loss of attendance records Large-capacity high-speed memory, support 2000 face, 2000 password, 2000 RFID cards (optional), 200,000 record capacity. Suitable for enterprises of all sizes (If you need a large capacity, we also have 5000 user capacity version, which is support 5000 face, 5000 password.)

Support off-line or TCP / IP using, or support WIFI

1, This device support to check-in to attendance without networking. Doesn't need to wiring and connect the network. Support to use U-disk to download and upload the attendance report data. (Doesn't include U disk. If you need it, you should buy it in additional.)

2, This device support to connect to computer through the TCP/IP communication network, download the attendance report data on the computer.

3, This device support to connect to computer through the Wifi communication network, download the attendance report data on the computer.

Product Analysis:

Product Specifications:

Material: high quality plastic Processor: 4-core 1.2G Operating memory capacity: 1G DDR3 Storage capacity: 8G eMMC Operating system: LINUX intelligent operating system Display: 4.3 inches Screen resolution: 480 * 272 Camera: 200W pixel HD color camera, 100W infrared camera Fill light: LED highlight fill light, dual infrared high power fill light Ambient light: 0-50000Lux Dynamic range: 120dB Face capacity: 5000/2000 Password capacity: 5000/2000 Card capacity: 5000 groups User records: 200,000 Identification method: face, password verification, card (optional) Face recognition mode: 1: 1, 1: N Identification function: name identification, work number identification Face recognition time: less than 200MS Intelligent function: infrared live detection Recognition distance: 0.5-2 meters Keyboard: On-screen touch virtual keyboard Communication interface: TCP / IP, USB, WIFI (optional) Rejection rate: <= 0.1% Misunderstanding rate: <= 0.0001% Working voltage: DC12V ± 10% Power requirements: DC 12V, 3 ~ 5A Working temperature: -15 ° C to 60 ° C, <90 ° C RHIP65 Appearance size: 200mm * 95mm * 25mm

Wiring Diagram:

1. If you want to use it as face time attendance machine, just connect it to a DC12V power plug then ok. (this package including a power plug) 2. If you want to use it as a face access control keypad, then must need to work with DC12V power supply, electric lock, exit button. (Note: the access control power supply, locks, exit button, door bell are NOT included in the package, need to buy in extra.)

Identification distance is 0.5-2 meters, installation height can be 1.2-1.5 meters

Package List:

1 x Dynamic Facial Access Control Machine 1 x CD Disk (including software) 1 x Mounting Bracket 1 x Screw Kit 1 x Power Adapter (US / EU / AU / UK plug optional) 1 x English User Manual 10 x 125KHz RFID Cards (Optional)

Very Important:

Please leave us message which type of the power plug you want, otherwise, we will send EU type by default.
